Stellar Industrial | Seco | CCMT 21.51-F1 TS2000 INSERT

content loaded

Seco

CCMT 21.51-F1 TS2000 INSERT

ccmt 21.51-f1 ts2000 insert

Stellar Part #SECCA 02615873

MFG Part #02615873

MFG Name:Seco Tools

Technical Specifications
Resources

Country of Origin:

Manufacturer Name:

Seco Tools

ANSI Code:

CCMT21.51-F1 TS2000, DDJNL2525M11

Chipbreaker:

Corner Radius:

0.4 mm

Cutting Direction:

Left Hand, Neutral

Finish:

TiAlN/TiN

For Use On:

Stainless Steel and Titanium/Super Alloys

Hole Diameter:

2.9 mm

Included Angle:

80 deg

Inscribed Circle:

0.3748 in, 6.4 mm

Insert Size:

060204

Insert Style:

CCMT

ISO Code:

CCMT060204-F1 TS2000, DDJNL2525M11

Manufacturer's Grade:

TS2000

Material:

Carbide, Steel

Material Grade:

M, S, M/S

Maximum Depth of Cut:

2.5 mm

Rake:

Negative, Positive

Relief Angle:

7 deg

Seat Size:

Shape:

Diamond

Thickness:

2.38 mm

: Country of Origin:
SE
Manufacturer Name:
Seco Tools
ANSI Code:
CCMT21.51-F1 TS2000, DDJNL2525M11
Chipbreaker:
F1
Corner Radius:
0.4 mm
Cutting Direction:
Left Hand, Neutral
Finish:
TiAlN/TiN
For Use On:
Stainless Steel and Titanium/Super Alloys
Hole Diameter:
2.9 mm
Included Angle:
80 deg
Inscribed Circle:
0.3748 in, 6.4 mm
Insert Size:
060204
Insert Style:
CCMT
ISO Code:
CCMT060204-F1 TS2000, DDJNL2525M11
Manufacturer's Grade:
TS2000
Material:
Carbide, Steel
Material Grade:
M, S, M/S
Maximum Depth of Cut:
2.5 mm
Rake:
Negative, Positive
Relief Angle:
7 deg
Seat Size:
06
Shape:
Diamond
Thickness:
2.38 mm
