Seco

DRILL TIP EXCHANGEABLE 16 TO 16.99MM 8XD

indexablecemills r217.29 m12 17mm 51.8mm

Stellar Part #SECCA 02623632

MFG Part #00040297

MFG Name:Seco Tools

Product Description:

Seco 02623632 Crownloc Plus Right Hand Exchangeable Tip Drill, 16 to 16.99 mm Drill, SD400 Insert, 212.9 mm OAL, 8XD Drill Depth by Dia Ratio, 20 mm Dia Shank, SD408 Toolholder

Technical Specifications

Insert Style:

RD0803, SD400

Modular Connection Thread Size:

M12

Shank Length:

50 mm

Cutting Diameter:

17 mm

Maximum Depth of Cut:

4 mm

Number of Inserts:

Overall Length:

212.9 mm, 51.8 mm

Series:

Crownloc® Plus, R217.29

Shank Diameter:

20 mm

Shank Type:

Combimaster, Cylindrical

Toolholder Type:

SD408

Type:

Indexable, Right Hand

: Insert Style:
RD0803, SD400
Modular Connection Thread Size:
M12
Shank Length:
50 mm
Cutting Diameter:
17 mm
Maximum Depth of Cut:
4 mm
Number of Inserts:
4
Overall Length:
212.9 mm, 51.8 mm
Series:
Crownloc® Plus, R217.29
Shank Diameter:
20 mm
Shank Type:
Combimaster, Cylindrical
Toolholder Type:
SD408
Type:
Indexable, Right Hand
