EATON FAZ-D15/3 Supplementary Protector, 480Y/277 V AC, 15 A, 7.5 to 15 kA Interrupt, 3 Poles, Thermal Magnetic Trip
protector supplementary 480y/277vac 15a
Stellar Part #EATON FAZ-D15-3
MFG Part #FAZ-D15/3
MFG Name:Eaton
Product Description:
EATON Supplementary Protector, Series: FAZ, 480Y/277 V AC, 15 A, 7.5 to 15 kA Interrupt, Thermal Magnetic Trip, 3 Pole, Line/Load Side Standard Terminal Connection, 18 to 4 AWG Wire, IP20 Enclosure, DIN Rail Mounting, -40 to 167 deg F, 2.09 in W x 2.36 in D x 3.15 in H Dimensions, Nylon
Login For Price
- Technical Specifications
- Resources
- Amperage Rating:15 AConnection Type:Line/Load Side Standard TerminalCountry of Origin:RODimensions:2.09 in W x 2.36 in D x 3.15 in HEnclosure Type:IP20Interrupt Rating:7.5 to 15 kAManufacturer Name:EatonMaterial:NylonMounting Type:DIN RailNumber of Poles:3Series:FAZTemperature Rating:-40 to 167 deg FTrip Type:Thermal MagneticVoltage Rating:480Y/277 V ACWire Size:18 to 4 AWG
