Seco

INSERT TURN CCMT M S 09T304 DMD 09 POS

insert turn ccmt m s 09t304 dmd 09 pos

Stellar Part #SECCA 06757

MFG Part #2430103

MFG Name:Seco Tools

Product Description:

Seco 02430103 Turning Insert, ANSI Code: CCMT32.51-F1 CP200, CCMT Insert, Material Grade: M, S, 09T304 Insert, Diamond Shape, 09 Seat, Positive Rake, Neutral Cutting, For Use On Stainless Steel and Titanium/Super Alloys, Carbide, Manufacturers Grade: CP20

Technical Specifications

ANSI Code:

CCMT32.51-F1 CP200

Chipbreaker:

Corner Radius:

0.4 mm

Cutting Direction:

Neutral

Finish:

PVD-TiAlN+TiN Coated

For Use On:

Stainless Steel and Titanium/Super Alloys

Hole Diameter:

4.5 mm

Included Angle:

80 deg

Inscribed Circle:

9.5 mm

Insert Size:

09T304

Insert Style:

CCMT

ISO Code:

CCMT09T304-F1 CP200

Manufacturer's Grade:

CP200

Material:

Carbide

Material Grade:

M, S

Maximum Depth of Cut:

3.5 mm

Rake:

Positive

Relief Angle:

7 deg

Seat Size:

Shape:

Diamond

Thickness:

3.97 mm

: ANSI Code:
CCMT32.51-F1 CP200
Chipbreaker:
F1
Corner Radius:
0.4 mm
Cutting Direction:
Neutral
Finish:
PVD-TiAlN+TiN Coated
For Use On:
Stainless Steel and Titanium/Super Alloys
Hole Diameter:
4.5 mm
Included Angle:
80 deg
Inscribed Circle:
9.5 mm
Insert Size:
09T304
Insert Style:
CCMT
ISO Code:
CCMT09T304-F1 CP200
Manufacturer's Grade:
CP200
Material:
Carbide
Material Grade:
M, S
Maximum Depth of Cut:
3.5 mm
Rake:
Positive
Relief Angle:
7 deg
Seat Size:
9
Shape:
Diamond
Thickness:
3.97 mm
