Sandvik Coromant 5731988 T-Max® P Turning Insert, ANSI Code: DNGA433S0330A 7025, DNGA Insert, Material Grade: H, 433 Insert, Diamond Shape, 15 Seat, Neutral Rake, Neutral Cutting, For Use On Hardened Steel, Carbide, Manufacturer's Grade: 7025
insert cbn
Stellar Part #SANCO DNGA433S0330A7025
MFG Part #5731988
MFG Name:Sandvik Coromant
Product Description:
Sandvik Coromant Turning Insert, Series: T-Max® P, DNGA Insert, 433 Insert, Diamond, 1.2 mm Maximum Depth of Cut, 1/2 in Inscribed Circle, 0.1874 in Thickness, 15 Seat, Neutral Rake, PM Chipbreaker, 0.047 in Corner Radius, 0.2029 in Hole Dia, Manufacturer's Grade: 7025, ANSI Code: DNGA433S0330A 7025, ISO Code: DNGA150412S01030A 7025, 55 deg Included Angle, 0 deg Relief Angle, Neutral Cutting, Carbide, Uncoated, Material Grade: H, For Use On: Hardened Steel
Login For Price
- Item Features
- Technical Specifications
- Resources
- Excellent surface finish
- Reliable and secure machining, even in roughing applications
- Possibility to optimize by using damped Silent Tools™
- Excellent surface finish
- Reliable and secure machining, even in roughing applications
- Possibility to optimize by using damped Silent Tools™
- Cutting Direction:NeutralFinish:UncoatedInsert Style:DNGAMaterial:CarbideSeries:T-Max P, T-Max® PThickness:0.1874 inANSI Code:DNGA433S0330A 7025Chipbreaker:PMCorner Radius:0.047 inFor Use On:Hardened SteelHole Diameter:0.2029 inIncluded Angle:55 degInscribed Circle:1/2 inInsert Size:433ISO Code:DNGA150412S01030A 7025Manufacturer's Grade:7025Material Grade:HMaximum Depth of Cut:1.2 mmRake:NeutralRelief Angle:0 degSeat Size:15Shape:Diamond
