bar boring indexable a..dclnl 1.575in

Stellar Part #SANCO 5722366

MFG Part #5722366

MFG Name:Sandvik Coromant

Sandvik Coromant 5722366 T-Max P Indexable Boring Bar, A..DCLNL Toolholder, 1.575 in Dia Min Bore, Left Hand of Holder, 11.811 in OAL

Hand of Holder:

Left

Inscribed Circle:

1/2 in

Insert Compatibility:

CNMG 12 04 08

Insert Shape:

80 deg Diamond, 80 deg Diamond/Rhombic

Insert Thickness:

0.187 in

Material:

Steel

Maximum Bore Depth:

5.039 in

Minimum Bore Diameter:

1.575 in

Overall Length:

11.811 in

Series:

T-Max® P

Shank Diameter:

1.26 in

Shank Type:

Cylindrical with 3-Flat

Through Coolant (Yes/No):

Yes

Toolholder Type:

A..DCLNL
