Stellar Part #SANCO 7859205
MFG Part #7859205
MFG Name:Sandvik Coromant
Product Description:
Sandvik Coromant 7859205 T-Max P Turning Insert, ANSI Code: CNMM 644-PR 4415, CNMM Insert, 644 Insert, Diamond Shape, Left/Right Hand Cutting, For Use On Cast Iron and Steel, Carbide, Manufacturers Grade: 4415
Login For Price
- Technical Specifications
- Resources
- ANSI Code:CNMM 644-PR 4415Chipbreaker:Single-Sided PRCorner Radius:1/16 inCutting Direction:Left/Right HandFinish:CVD-TiCN+Al2O3+TiN Coated, TiCN/Al2O3/TiNFor Use On:Cast Iron and SteelHole Diameter:>50 mmIncluded Angle:80 degInscribed Circle:3/4 inInsert Size:644Insert Style:CNMMISO Code:CNMM 19 06 16-PR 4415Length:0.698579 inManufacturer's Grade:4415Material:CarbideMaximum Depth of Cut:12 mmRelief Angle:0 degSeries:T-Max® PShape:DiamondThickness:1/4 inCountry of Origin:SEManufacturer Name:Sandvik Coromant
